1m 8.3 Micron Fiber Optic Pigtail

Product Categories
Wuhan Geehe Optical Communication Co.,ltd
Contact Now

1m 8.3 Micron Fiber Optic Pigtail

Brand Name : Geehe (OEM Service)

Model Number : GH-FP-Pigtail-003

Certification : ISO9001:2015,ISO:14001:2015,UL

Place of Origin : Wuhan,China

MOQ : 1,000pcs

Price : Negotiation

Payment Terms : T/T, D/A, Western Union, MoneyGram,, Western Union

Supply Ability : 10,000 pcs per day

Delivery Time : Within 5-7 working days to delivery

Packaging Details : Plastic box per pc with QC test report outer carton

Model Name : Pigtail fiber optic

Fiber Type : Singlemode OS2

Core Diameter : 8.3 Micron

Cable Jacket : PVC/LSZH/OFNP

Fiber Grade : G.652.D/G.657.A1

Cable Length : 1M, 2M, 3M,20M,100MOr Customized

Number of Fibers : 1

Connectors (End 1) : One ST

Minimum Bend Radius : 30 mm/10 mm

Durability : ＞1000 times

Contact Now

Single Strand 2 Meter ST Single-Mode OS2 1 Meter Pigtail Fiber Optic



Basic Information:

Geehe supply quality ST Single-mode Fiber Optic Pigtails are 3 meters long with a 900um outer jacket. Ideal for fusion splicing.
We also offer custom-made specification pigtail, it is available in simplex presentation with UPC or APC polished. Standard lengths are 1M,2M,3M,4M,5M to 500m.

The cables are available in different configurations:

Pigtail Fiber Optic OS2 9/125
Pigtail Fiber Optic Multimode OM1 62.5 / 125
Pigtail Fiber Optic Multimode OM3 50/125
Pigtail Multimode OM4 Fiber Optic 50/125


Connectors: FC, SC, LC, MU, ST, MT-RJ, etc connector.



Features And Benefits of ST Pigtails:

1) Superior qualified standard PC, APC, UPC, SPC polishing
2) 100% optic test: Insertion Loss: ≤0.3 (PC); ≤0.2 (APC); ≤0.2 (UPC); ≤0.3 (SPC)
3) φ0.9mm, φ2.0mm, φ3.0mm cable optional
4) Single-mode (9125) or multi-mode (50/125 or 62.5/125) fiber available
5) Good exchangeability and good durability
6) Available in fiber bunch, ribbon fan-out, pigtail available
7) Meets ISO9001, ROHS, and Bell core GR 326-core standard
8) Customized specifications are welcomed

1m 8.3 Micron Fiber Optic Pigtail


Applications of SC/APC Single Mode Pigtails:

1) CATV, metro test equipment
2) Telecommunication networks
3) Local area networks (LAN)
4) Wide area networks (WAN)
5) Premise installations
6) Video and military active device termination

1m 8.3 Micron Fiber Optic Pigtail

Specification &Technology Parameters:

ItemSM (Single-Mode)MM (Multimode)
Fiber Cable TypeG625D/G655/G6571A/G657A2OM1OM2/OM3/OM4
Fiber Diameter (um)9/12562.5/12550/125
IL(dB)≤0.3≤0.1
Cable TypeSimplex, Duplex, Fan-Out
Connector TypeLC, SC, FC, ST, MU, MPO, MTRJ, D4, DIN, SMA, FDDI,
ESCON etc.
Cable OD (um)0.9/1.6/1.8/2.0/2.4/2.8/3.0
End-face TypePCUPCAPCUPCUPC
Retun Loss(dB)>45>50>60/
Insert-pull Test (dB)<0.2<0.3<0.15
Interchangeability (dB)<0.1<0.15<0.1
Mating Times>1000
Anti-tensile Force (N)>70
Temperature Range (℃)-40~+80


ST Single Pigtails Specification:

ParameterUnitIndex
End-Face Type PCUPCAPC
ILdBSM: ≤0.3；MM ≤0.1
RepeatabilitydB≤0.1
InterchangeabilitydB≤0.2
RLSMdB≥45≥50≥60
MMdB≥36(Exclusive APC Connector )
Mating Times ＞1000
Operating Temperature℃-40~ +80


































































Product Tags:

8.3 Micron Fiber Optic Pigtail



8.3 Micron optical fiber pigtail



8.3 Micron single mode fiber pigtails


Quality 1m 8.3 Micron Fiber Optic Pigtail wholesale
